Engine specification
engine name |
Hi-Rapier NO-GA |
base engine | Honda C50-E |
engine type | gasoline-4cycle |
cylinder | 1 |
cylinder stroke-bore ratio | 39.0*41.4 |
engine capacity | 49.46cc |
compression ratio | |
style of combustion chamber | hemispherical combustion chamber |
combustion chamber volume | |
valve layout | SOHC,chain |
number of valves | IN 1,EX 1 |
valve spring | IN 1,EX 1 |
valve clearance | IN 0.08mm,EX 0.05mm |
valve lift quantity | IN 3mm,EX 3mm |
valve timing I.O. | 18°BTDC(0.1mm lift) |
I.C. | 60°ABDC(0.1mm lift) |
E.O. | 52°BBDC(0.1mm lift) |
E.C. | 18°ATDC(0.1mm lift) |
start system | self starter motor |
ignition system | CDI |
ignition timing | 10°BTDC(advance) |
spark plug | NGK C5HA |
battery | GS(Nihon Denti),GM4-3B |
battery capacity | 12V 4Ah |
cooling system | water cooled |
cooler | handmade radiator |
volume of coolant | 250cc |
volume of lubricant | 5W-30,30cc |
lubrication system | weigh up. |
clutch type | centrifugal force expand inside. |
drive system | chain |
gear ratio | first 2.25,second 4.42 |
total gear ratio | 9.9375 |
carburetor type | KEIHIN PB-12 |
throttle valve diameter | 13mm |
venturi diameter | 12mm |
slow running jet | #38 |
main jet | #55 |
jet needle | #1 |
engine weight |
